Single Stage Air Washer (Single & Double Blower)

HUMIDIN SINGLE STAGE EVAPORATIVE COOLING UNIT

SINGLE-STAGE EVAPORATIVE COOLING UNIT is a type of air cooling system that uses the natural process of evaporation to reduce the temperature of the air. This system is often employed in environments where air conditioning may be inefficient or too expensive to operate. The basic principle behind evaporative cooling is the process where water evaporates and absorbs heat from the surrounding air, which leads to a reduction in air temperature. In a single-stage evaporative cooling unit, this process occurs in one main cooling stage, typically involving a pad system or cooling media that absorbs water, and air is then passed over it to produce cooler air.

Enquire Now Catalogue

Single Stage Air Washer (Single & Double Blower) - Technical Specifications

1. Type - Single Stage Air Washer
2. Blower Configuration - Single Blower / Double Blower
3. Air Volume Capacity - Available in multiple air Volume capacities as per requirement
4. Casing - Double-skin / Single-skin construction options
5. Cooling Method - Evaporative cooling through water circulation
6. Blower - Centrifugal blower for efficient air movement
7. Motor - Suitable motor capacity as per air Volume and static pressure
8. Filter - Pre-filter / washable filter options available
9. Water System - Pump, spray nozzles and efficient water circulation arrangement
10. Cooling Media - High-efficiency air-washing media
11. Drain & Overflow - Proper drain and overflow arrangement
12. Access - Easy-access panels for inspection and maintenance

Single Stage Air Washer (Single & Double Blower) - Description

Single Stage Air Washer is an efficient air-conditioning and air-cleaning unit designed to cool, humidify, and clean air through a water-washing process. Available with single or double blower configurations, it provides reliable air movement and effective cooling for commercial and industrial applications.
