Roof Extractor - Centrifugal Type

HUMIDIN ROOF EXTRACTOR FLOW FAN

ROOF EXTRACTOR FLOW FAN is a type of fan designed to be installed on the roof of a building, specifically used to exhaust air, smoke, or fumes from indoor spaces to the outside environment. It utilizes an axial flow mechanism, meaning that Air moves parallel to the axis of the fan, drawing air in and pushing it out in the same direction. These fans are particularly popular in ventilation and extraction systems, and they are often used to improve air quality & regulate temperature.

Enquire Now Catalogue

Technical Specification – Roof Extractor (Centrifugal Type)

1. Fan Type - Roof Mounted Centrifugal Extractor
2. Air Volume Capacity - As per system requirement
3. Static Pressure - As per system resistance
4. Fan Construction - Heavy-duty fabricated construction
5. Impeller Type - Backward-curved / Forward-curved centrifugal impeller
6. Impeller Material - GI / Mild Steel / Aluminium, as required
7. Casing Material - Galvanized Steel / Mild Steel
8. Motor Type - TEFC, 3-Phase / Single-Phase
9. Motor Efficiency - IE2 / IE3, as specified
10. Drive Arrangement - Direct Drive / Belt Drive
11. Power Supply - 415 V, 50 Hz, 3-Phase (standard)
12. Speed - As per selected fan duty
13. Mounting -Roof Mounted
14. Discharge - Vertical Upward Discharge
15. Weather Protection - Weather-resistant roof housing
16. Noise Level - As per applicable project requirement
17. Balancing - Dynamically balanced impeller
18. Application - Industrial exhaust, warehouse ventilation, kitchen exhaust, heat extraction, process ventilation, and general air extraction

ROOF EXTRACTOR – CENTRIFUGAL TYPE

A Centrifugal Roof Extractor is a roof-mounted ventilation system designed to efficiently remove stale, hot, humid, and contaminated air from industrial and commercial spaces. Its centrifugal impeller provides reliable air extraction while the roof-mounted design saves indoor space and supports continuous ventilation.
